PP Dome Type Fiber Optic Splice Closure 2 Inlet 2 Outlet 288 Core

Brand Name : Focus Infra or OEM

Model Number : FS-J-021

Place of Origin : China

MOQ : 50pcs

Price : Negotiable

Supply Ability : 500000pcs per month

Packaging Details : 1 pcs per carton

Product Name : 288 Core Horizontal Type Outdoor Aerial Dome Fiber Optical Cable Splice Joint Storage Outlet Box

Protection level : IP 68

Cable Port : 2 inlets 2 outlets

Scope of application : 12 core to 288 core

Product size : 420*240*140mm

Gross weight : 5 kg

Main material : PP

Ambient temperature : - 40 °C ~ + 60 °C

Contact Now

288 Core Horizontal Type Outdoor Aerial Dome Fiber Optical Cable Splice Joint Storage Outlet Box

Description:

According to the appearance structure can be divided into Dome type cable joint box and horizontal cable joint box. 288 Core Horizontal Type Outdoor Aerial Dome Fiber Optical Cable Splice Joint Storage Outlet Box, also known as 288 Core Horizontal Type Outdoor Aerial Dome Fiber Optical Cable Splice Joint Storage Outlet Closure, is the place where the end of optical cable is connected. 288 Core Horizontal Type Outdoor Aerial Dome Fiber Optical Cable Splice Joint Storage Outlet Box are widely apply for the connecting of optical cable.It Suitable for straight-through, diverging and connection of FTTH. FTTB all kinds of optical communication passive network. it is one of the common equipment of user access points, mainly completing the outdoor connection between wiring cable and household cable, and the cassette or simple optical separator can be installed according to the FTTX access needs.

Specification:

Product name 288 core Horizontal Type Cable Joint Box
Protection level IP68
Scope of application 12 core to 288 core
Gross weight 5 kg
Main material PP
Scope of use Outdoor Aerial Dome,Buried,pole mount type outdoor
Ambient temperature - 40 °C ~ + 60 °C
Service life ≥20 years
Application scope FTTH FTTB FTTX Network
Atmospheric pressure 70kPa~106kPa
Insulation resistance >2*10MΩ/500V(pc)
Tensile strength >1200N

Features:

IP66 Water-proof design for outdoor uses;

Grouping function: 2 inlet 2 outlet can meet most requirements;

Splice tray: using cascading structure, no need to take other splice tray when do operation;

Applications:

Used for direct transmission of outdoor cable in aerial,

duct and direct buried application
Used for branching connection and protect the joint

PP Dome Type Fiber Optic Splice Closure 2 Inlet 2 Outlet 288 CorePP Dome Type Fiber Optic Splice Closure 2 Inlet 2 Outlet 288 CorePP Dome Type Fiber Optic Splice Closure 2 Inlet 2 Outlet 288 CorePP Dome Type Fiber Optic Splice Closure 2 Inlet 2 Outlet 288 Core

PP Dome Type Fiber Optic Splice Closure 2 Inlet 2 Outlet 288 CorePP Dome Type Fiber Optic Splice Closure 2 Inlet 2 Outlet 288 Core
